HAAS ST-15 CNC lathe

HAAS ST-15 CNC lathe was built in 2020 in the United States by HAAS AUTOMATION, INC. This highly efficient machine with a compact design is an excellent choice for both unit and series production. Workpieces with a maximum length of 406 mm are machined inside a large workspace by means of a high-speed spindle and precision cutting tools, taken from a 12-position turret. All this is complemented by intelligent CNC control, in which advanced machining programmes are created in just a few steps. The HAAS ST15 CNC turning center weighs 3584 kg. Technical specifications of the HAAS ST-15 metal lathe CNC controller: HAAS swing over over bed: 419 mm bar diameter: 64 mm maximum turning length: 406 mm feed in the X/Z axis: 200/406 mm rapid traverse in the X,Z axis: 30.5 m/min thrust force in the X,Z axis: 14679 N maximum spindle rotational speed: 4000 rpm maximum spindle torque (at 500 rpm): 203 Nm spindle drive power: 14.9 kW spindle bore diameter: 88.9 mm spindle end: A2-6 12-position turret chuck diameter: 210 mm manual tailstock positioning: 508 mm tailstock quill extension: 95 mm tailstock quill cone: MT3 coolant tank capacity: 114 l air consumption: 113 l/min air pressure: 6.9 bar power supply: 3x 440 V; 50/60 Hz weight of the HAAS ST-15 machine: 3584 kg (The technical parameters given were obtained from the machine manufacturer’s website. Their accuracy cannot be guaranteed and they may therefore differ slightly from reality.)
